Magnesia chromite bricks are a type of refractory brick that is commonly used in high-temperature applications, such as in steel, non-ferrous metal, and glass industries. These bricks are known for their excellent resistance to corrosion and high thermal stability.
Payment :
In AdvanceProduct Origin :
ChinaShipping Port :
Shanghai PortLead Time :
15 Working daysData:
| ITEM No | Magnesia Chromite Brick---(DYS B622) | ||
| Physical Property: | |||
| Bulk Density(g/cm3) | ≥ | 2.95 | |
| Apparent Porosity(%) | ≤ | 18 | |
| Cold Crushing Strength(MPa) | ≥ | 40 | |
| Refractoriness Under Load(T0.6 ºC) | ≥ | 1580 | |
| Thermal Expansion( 1400ºC) (%) | * | 1.5 | |
| Thermal Conductivity (1000ºC)(W/m.K) | ≤ | 2.8 | |
| Thermal Shock Resistance( 950ºC,Air)(Cycles) | ≥ | 80 | |
| Chemical Analysis(%) | |||
| MgO | ≥ | 75 | |
| Cr2O3 | ≥ | 8.0 | |
| SiO2 | ≤ | 2.0 | |
| Note:All data are average values obtained at samples for laboratory purposes. | |||
| Application:Cement Rotary Kiln | |||
DYSen Magnesia Chromite Bricks are manufactured under strict quality-control system and designed for cement rotary kilns
Competitive prices, high flexibility and low thermal conductivity are key performance for using magnesia chromite bricks.
In order to decrease downtime and increase cost effectiveness, we recommend you optimal solutions upon your specific requirement and application,including consultancy,design,installation and maintenance.
Application
1.Cement burning zone & Transition zones with increased thermal load
2.LTZ/CBZ/UTZ
Physical properties
a.Low thermal conductivity
b.High refractoriness
c.High flexibility
d.Strong abrasion resistance
e.High chemical attack resistance
f.Outstanding coating friendly
Raw materials
1.Natural,high-purity fused magnesia
2.Chrome Ore
3.Direct-bonded
